CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill

Name: CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill
Brand: CS Unitec
SKU: MABASIC 400
Price: 1161.99 USD
Availability: InStock

SKU# MABASIC 400

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill, large image number 0

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill, large image number 1

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill, large image number 2

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill, large image number 3

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill, large image number 4

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill, large image number 5

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill, large image number 6

+ 3 more

Acme Tools Guarantee

Qty

(Max. order of 1,000)

Secure Checkout

Product Details

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill

CS Unitec

Please follow our Community Guidelines and be kind!

Description

CS Unitec 1-5/8 Inch 2-Speed Magnetic Drill

CS Unitec’s MABasic line of magnetic drills consists of powerful and reliable machines at an affordable price, a perfect blend of power, endurance and economy. The MABasic 400 magnetic drill is a heavy-duty, workhorse with: 9.5 Amp motor, 2-speed gearbox (430/760RPM), and a 6-1/3" stroke. The MABasic 400 drills up to 1-5/8” dia. with annular cutters in structural steel and other metals. The drill accepts cutters with a 3/4” Weldon Shank. With included drill chuck, this model easily converts to a standard drill press for conventional twist drilling up to 5/8” diameter. Compact (14" tall) and lightweight (27 lbs.), the MABasic 400 is easily portable to the jobsite, making it the hole-cutting solution for steel fabricators and contractors, as well as plant maintenance operations. The MABasic 400 is equipped with an internal automatic lubrication system that increases the life of annular cutters by reducing friction and wear. The Electronic Safety Shutoff Sensor automatically shuts down the drill if the magnet loses contact with the material, protecting both operator and equipment. The machine’s magnet has a holding strength of 3,080 lbs.

California Proposition 65 Warning.

Features

Heavy-duty, purpose-built, 2-speed workhorse

1-5/8" diameter hole cutting capacity

Powerful and reliable machines at an affordable price

Excellent Power To Weight Ratio, Only 27 lbs

Compact, lightweight, portable design

Internal lubrication system

Simple, ergonomic arrangement of controls for one-handed operation

Emergency-off function: electronic safety sensor shuts down drill motor if magnet loses contact with material to protect operator and equipment

3/4" Weldon tool holder

Specifications

Brand Name

CS Unitec

Assembled Weight (lbs)

Country of Origin

Germany

MFG Part # (OEM)

MABASIC 400

Package Contents

(1) MABasic 400 (1) Carrying Case (1) Safety Strap (1) Operating manual (1) Warranty Certificate (1) Coolant bottle (2) Pilot/Ejector Pin (2) Hex Keys (1) 3/4" Weldon Tool Holder w/ internal Lubrication, Affixed (1) 1/2" Geared Chuck
