EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle

SKU# EI10V080V1DK
EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle, large image number 0
EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle, large image number 1
EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle, large image number 2
EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle, large image number 3
EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle, large image number 4
Previous Next
What's included
2 Items
EMAX 115V 1 Phase 58 Cfm Industrial Refrigerated Compressed Air Dryer, large image number 0

EMAX 115V 1 Phase 58 Cfm Industrial Refrigerated Compressed Air Dryer

SKU# EDRCF1150058

Item Count: 1

$3,434.85
Secure Checkout
EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor, large image number 0

EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor

SKU# EI10V080V1

Item Count: 1

$4,569.70
Secure Checkout
Discontinued by Manufacturer
Contact for more Information: 877-345-2263

Product Details

EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle
EMAX

Please follow our Community Guidelines and be kind!

Description

EMAX 80 Gallon 175 Psi 10HP Vertical Air Compressor with 115V Air Dryer Bundle

Our industrial series offers all the same quality and durability as our plus series without all the extra cost of added features. We offer this series so that anyone can afford to have an EMAX compressor. EMAX industrial 10 P 2 stage V4, 1 Phase vertical 80 gallon. Piston air compressor is designed for up to 70000 hours of commercial or industrial use with proper maintenance. This unit delivers 38 SCfm at 100 Psi, top Psi of 175. Our unit features industrial ODP electric motors, condor pressure switch, manual ball valve tank drain, powder coated ASME tank 200 Psi rating, all paired with all cast iron 70000 hour. rated patented pressure lubricated reciprocating pump. Our Emax air dryer is the only energy efficient dryer systems with aluminum refrigerated air inner cooler. The air is filtered of all solid particles 0.01 micron and larger. Clean, dry compressed air leaving the dryer minimizes maintenance and repair and also reduces internal dryer contamination. We designed them with Non-corrosive inner and after cooler. Our dryers feature stainless steel heat exchanger for maximum dryer life and less maintenance. Emax Air dryers are UL-CSA approved scroll compressor & electric system for high efficiency and durability. They feature adjustable hot bypass for complete dryer function in low and high Cfm flow preventing dryer freeze up.

California Proposition 65 Warning.

Manuals

Installation Guide - PDF

Features

EI10V080V1: All steel connecting rods with replaceable rod bearing inserts, this allows our rods to be rebuilt! 99% of our competitors now use "throw-away" aluminum connecting rods in their pumps that have no re-build capability
EI10V080V1: Removable 100% cast iron cylinders, these solid cast iron cylinders are more stable under heavy workloads and do not warp from heat
EI10V080V1: All cast iron cylinder heads, cast iron heads are more durable and dependable for trouble free operation
EI10V080V1: Disc valve design" intake and exhaust valves, disc valves have been around for over 100 years and have been proven to perform
EDRCF1150058: Purifies compressed air by chilling to condense moisture
EDRCF1150058: Condensate is drained carrying oil & dirt partials away from the air
EDRCF1150058: Auto drain system - eliminates the need for daily maintenance
EI10V080V1: Re-usable oil filter
EDRCF1150058: Refrigerant pressure - gauge clearly monitors performance of dew point temp (models under 400 Cfm)
EI10V080V1: Meets CSA, ASME, ETL standards

Specifications

Brand Name
EMAX
Air Volume (CFM)
38
Amperage (A)
40
Assembled Weight (lbs)
856
Average Air Consumption (CFM)
38
Compressor Design
Vertical
Country of Origin
United States
Horsepower (hp)
10

MFG Part # (OEM)
EI10V080V1DK

Material
Solid Cast Iron Pump
Maximum Air Pressure (psi)
175
Maximum Pressure Rating (psi)
175
Maximum RPM
1750
Maximum Speed (rpm)
1750
Package Contents
(1) EDRCF1150058 115V 1 Phase 58 Cfm Industrial Refrigerated Compressed Air Dryer, (1) EI10V080V1 80 Gallon 175 Psi 10HP Vertical Air Compressor
Phase
Single Phase

Product Condition
New

RPM
1750
Restrictions
CA Prop 65
Size
28 In. Length x 42 In. Width x 72 In. Height x 3/4 In. Tank Outlet Size
Tank Capacity (gal)
80

UPC
405010002219

Voltage
230 Volts
Warranty Type
1 Year
Weight (lbs)
870
