JET Gear Head 16 x 60 ZX Lathe with Taper Attachment Installed
JET

Please follow our Community Guidelines and be kind!

Description

JET Gear Head 16 x 60 ZX Lathe with Taper Attachment Installed

JET®'s extensive selection of turning machines allows the experts to choose the lathes they need to perform any turning operation. Precision manufactured to meet the demands of even the highest volume shop, JET® turning machines, taper attachments, collet closers, digital readouts and accessories are built to last. JET® machines are backed by an industry - best two year warranty, and come with superior customer support like professional manuals to ensure precise, accurate and efficient operation.

California Proposition 65 Warning.
View Warning Label

Features

Uniquely designed exclusively by Jet
ISO 91 certified manufacturer
3-1/8 In. bore spindle is supported by two tapered and one ball bearing
Chrome molybdenum headstock gears are hardened, ground and shaved
Universal gearbox allows inch, metric, diametrical and module pitch threads, no change gears required
Carriage features one-shot lubrication and Turcite-B on bed sliding surfaces
T-slotted compound slide featuring four-way tool post
One piece cast iron base absorbs vibration allowing heavier cuts
High quality ANSI class 50 wear resistant cast iron bed ways are hardened and ground
Removable gap allows up to 23-5/8 In. diameter work on 16 In., 27-1/2 In. on 18 In.

Specifications

Brand Name
JET
Assembled Weight (lbs)
6200
California Proposition 65 Warning Required
Yes
Center To Center (in)
40
Country of Origin
China
CSA Certified
No
ETL Listed
No
Height (in)
48
Horsepower (hp)
7.5
Lock-on Switch
Yes

MFG Part # (OEM)
JT9-321477

Maximum Speed (rpm)
1800
Net Tool Weight (lbs)
0
Package Contents
Gear Head 16 x 60 ZX Lathe with Taper Attachment Installed
Phase
Three Phase

Product Condition
New

Spindle Bore Diameter
3.125
Stand Included
Yes
Swing Over Bed
16
Switch Type
Push Button
UL Listed
No

UPC
662755515071

Variable Speed
Yes
Voltage
230/460 Volts
Warranty Type
2 Years Limited
Weight (lbs)
6200
