Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors

Name: Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors
Brand: Land Pride
SKU: BB2572-82

SKU# BB2572-82

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 0

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 1

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 2

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 3

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 4

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 5

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 6

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 7

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 8

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 9

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 10

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors, large image number 11

+ 8 more

Call for Pricing Information: 833-860-7137

Made In USA

Freight Shipping Rates Apply

Calculated Delivery Rate at Checkout

Acme Tools Guarantee

Product Details

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors

Land Pride

Please follow our Community Guidelines and be kind!

Description

Land Pride BB2572 72 Inch Box Scraper for Kubota 25-55HP Tractors

This new Land Pride BB2572 72 In. box scrapers is designed for use with Category 1 3-point hitches or quick-hitch systems on tractors in the 55HP range. Ideal for building sites, feedlots, outdoor arenas, and on farm and ranch lanes or roadways. Two welded braces extending from front to rear of bucket plus welded gussets between the side panels and moldboard provide exceptional strength for keeping the Box Scraper square under heavy loads. Dirt rolls off of the roll-formed moldboard while scraping, creating less drag and you will get twice the wear on the cutting edge due to its reversibility. With a capacity of 14.7 Cu-Ft., it's built for tough jobs. Located at Acme Equipment-3401 Gateway Drive, Grand Forks, ND 58203.

California Proposition 65 Warning.

Manuals

Use and Care Manual - PDF

Warranty - PDF

Specification - PDF

Features

Quick-hitch compatible - Our Quick-Hitch System allows you to quickly connect and disconnect from the implement - most without leaving the tractor seat. This is a real time saver when working on multiple projects. Heat-treated, reversible, and replaceable cutting blades - Heat-treated for hardness. Reversible so both edges can be used before replacing the cutting blades.

Heavy side panels - 5-16 In. & 3/8 In. (8 & 10 mm) built heavy to handle the tough jobs. Rear backfill blade - Rear backfill blade allows for backfilling trenches or foundations.

Square tubing shank support - Many competitors use angle iron. Box tubing is stronger. Category 1 3-point hitch with Quick Hitch capability - Fits a wide variety of tractors. Quick Hitch capability allows for easy hook-up.

Clevis-type lower 3-point hitch - Much stronger than pin type hitch. Heavy 4 In. x 4 In. x 5/16 in. front beam with 5/16 In. x 1 In. shank hole reinforcement - Reinforcement adds additional strength to shank tube right behind shank where maximum pressure is applied.

4 Position heat treated spring steel shanks - Offers flexibility for deep to shallow settings and Heat-treated for longevity. Strong bucket reinforcement BB25 Series - Two welded braces extending from front to rear of bucket plus welded gussets between the side panels and moldboard provide exceptional strength for keeping the box scraper square under heavy loads.

Horsepower range - 25-55HP (19-41 kW).

Roll-formed moldboard - Roll-formed moldboard keeps materials flowing which puts less drag on the box scraper, resulting in lower horsepower requirements and faster working conditions.

17 In. (43 cm) Moldboard height - High material capacity.

Moldboard - Heavy moldboard holds its shape under heavy loads.

Heat treated dimpled-on tips - Easy to replace tips that are heat treated for toughness. Number of shanks - 7.
