Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade

SKU# RB1560-82
3.3 out of 5 Customer Rating
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 0
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 1
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 2
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 3
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 4
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 5
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 6
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 7
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 8
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 9
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 10
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 11
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 12
Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade, large image number 13
Previous Next
+ 9 more
Call for Pricing Information: 833-860-7137
Made In USA

Freight Shipping Rates Apply
Affirm
Pay as low as $64/mo.
with Affirm

Product Details

Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade
Land Pride

Please follow our Community Guidelines and be kind!

Description

Land Pride RB1560 60 Inch RB05 Series Rear Tractor Blade

This new Land Pride 60 In. 3-point rear blade is designed tractors with 17-40HP and Category 1 hitch types. Equipped with the Land Pride quick hitch, it provides an economical solution for leveling, finish grading, and backfilling at feedlots, outdoor arenas, building sites, nurseries, and maintenance operations on farms, ranches, and property owner lanes and roadways. The multitude of forward and reverse working angles, as well as moldboard offset capability, allows the operator to work right up next to retaining walls, abutments, and raised curbing. They are excellent for snow removal in the pulling or push blade mode. A retractable parking stand is included to accommodate easier blade removal, storage, and remount capabilities. The blade is compatible with Kubota BX, B, LX, and L Series Tractors. Located at Acme Equipment-3401 Gateway Drive, Grand Forks, ND 58203.

California Proposition 65 Warning.

Manuals

Use and Care Manual - PDF
Warranty - PDF
Specification - PDF

Features

Quick-hitch compatible - Our quick-hitch system allows you to quickly connect and disconnect from the implement - most without leaving the tractor seat. This is a real time saver when working on multiple projects.
Blade angles left and right up to 45 deg in forward position and 30 deg in reverse position - (7 Forward positions in 15 deg increments and 5 reverse positions in 15 deg increments).Many angles for diverse jobs and results.
Blade offsets 12 In. left and right - Manually move moldboard to cover either tractor tire.
Rolled moldboard height: 14 In. (35.6 cm) Rolled moldboard allows material to flow easily, which means less drag, less HP. 1/4 In. (6 mm) Moldboard thickness Is just right for 40HP (29.8 kW) work.
Reversible cutting edge - For twice the life.
Park stand - Store unit with front of hitch off the ground, allows for easier implement connection.
Skid shoes (optional) - Set depth of blade to clear obstructions like manhole covers, street cracks.
Landscape Rake adaptable - Remove moldboard and add rake element to add diversity of frame.
Cutting edge: 1/2 In. x 6 In. heat treated, reversible, replaceable.

Specifications

Brand Name
Land Pride
Application
For Kubota 17-40HP BX, B, LX, L Series Tractors
Assembled Weight (lbs)
248
Attachment Method
Cat. 1, Quick Hitch
Blade Material
Metal
California Proposition 65 Warning Required
Yes
Color
Orange
Country of Origin
United States

MFG Part # (OEM)
RB1560-82

Overall Height (in)
37.625
Overall Length (in)
41
Overall Width (in)
60
Package Contents
(1) Rear Blade

Product Condition
New

Rust Resistant
Yes
Restrictions
CA Prop 65

UPC
418015000296

Warranty Type
1 Year Limited
Weight (lbs)
255
Part Number
RB1560-82
